## Designing Letters

The downloadable program for designing letters uses a coordinate system with an x and y-axis, with values from 0 to 100.

To show my oldest son how designing each letter would work, I wrote out a few diagrams for him. The x-axis is the letter width, with the value 50 being the most common. The y-axis is the letter height, with 100 being the maximum. The up-down arrow represents if the pen is on the paper or off the paper. x is false or pen on paper, and âˆš is true or pen off paper. Without that third variable you would just end up with scribble-scrabble on the paper instead of letters. To give him a place to start, we designed A, B, and C together. Each block on the page represents a line of a letter on the paper or a movement of the pen when off the paper. I went on to design the remaining letters on paper for him, but a few them didn’t work as written so he fiddled with the numbers until they made a recognizable form of that letter. Difficult letters: K (this one gave us a headache!), Q (how to get that little slash at the bottom), and Y. It was interesting to see how difficult it is to “teach” a robot to write when it comes to us so naturally (after learning in school of course!)

The robot has issues writing curved lines, so we tried to stick with as many block shapes as possible. Many of our letters ended up being a bit non-traditional in appearance.

Above, you can see some of our troubleshooting attempts. In the first banner, the pen was inserted too far. The last LEGO EV3 on that banner is after we moved the pen up a bit. The second pic has some of our very first attempts at even running the Print3r bot. As you can see, we had a long way to go! The third pic has a very interesting-looking Y. This is after we tried programming a few more letters and before we decided to go for the whole alphabet.

My son Corran exported all the alphabet letters here into a google drive link. So if you don’t have time to program all the letters, you can use ours instead. They are definitely not perfect, but they are a place to start! You will still need to download the PlotStep.ev3p file that I mentioned above.

The following link will allow you to download the same program that I linked to above. The only difference is that it contains all the letters of the alphabet also. Each tab within the program contains a different letter or punctuation mark.

To download the entire program, click the icon as circled in the above image.

The current program in the above pic is for the letter R. To access the other letters, click the circled icon (on mouse over, the text “program list” will appear) and a list of them will appear. Click the letter or punctuation needed and the tab will change to the programming for that letter. My son would build words or sentences to print using the word builder tab and would copy and paste the appropriate blocks into it. Notice that there is a “space” tab for  programming a space into a sentence, so that your words do not all run together into one. There is also a PrinterFeed tab to use for when you are finished printing.

## Printing customized messages

Here is a Video of the LEGO Mindstorms Banner Print3r bot printing our customized alphabet:

Just for fun, we had the Print3r bot print us a little ad for our website!

Here is a video of the LEGO Mindstorms Printer bot printing a very long message:

This was a particularly difficult LEGO Mindstorms project for us, so if anyone else who tries this build out has any issues, please ask us if we can help! It is a fun project though!

-Lynn

P.S. I have edited and reposted this blog post to make it more clear. I hope this will be a help to anyone who is working on this project! Please feel free to ask questions! I will do my best to answer them!
